| Technical data | AX8620-0000-0000 |
|---|---|
| Function | power supply module |
| Rated supply voltage | 1 x 100…240 V AC 3 x 200…480 V AC |
| DC link voltage | max. 848 V DC |
| DC link output current | 5/7 A DC (at single-phase feeding), 20 A DC |
| System bus | EtherCAT |
| Drive profile | CiA402 according to IEC 61800-7-201 (CoE) |
| Ambient temperature (operation) | 0…+40 °C, up to +55 °C with power reduction (see documentation) |
| Approvals/markings | CE, cULus, EAC |
| Housing data | AX862x |
|---|---|
| Protection rating | IP20 |
| Width | 60 mm |
